Oracal Commercial S-EXTERIOR window films are double-layer silver/metallised architectural window films for exterior application, with appropriate thickness and various shades. ORACAL COMMERCIAL S are window films manufactured using advanced technology. They reflect sunlight, thereby reducing the amount of solar energy penetrating the interior of the building. Not suitable for use on vehicles due to the mirror effect. The films are easy to apply using the appropriate tools and methods. Designed for wet application.

Silver architectural window film type external one-way mirror ORACAL Commercial S-EXTERIOR 05%, for use on external building windows, multi-layer, metallised, dark, transmits approx. 5.9% of visible light. For external use. Available in widths. 152 cm, glossy surface.

Technical data

• Visible light transmission - 5.9%
• Visible light reflection - 74.2%
• Solar energy transmission - 4.9%
• Solar energy reflection - 64.8%
• Solar energy absorption - 30.3%
• IR reduction - 95%
• UV reduction - 99%
• TSER (Total Solar Energy Rejected) - 86%
• Glare reduction - 93%
• Thickness - 75 microns
• Durability - 3 years - in Central European climate conditions, when properly applied
• Material - Single-sided silicone-coated transparent polyester (silicone: 0.25 g/m²)
• Adhesive - Acrylic adhesive, repositionable, transparent.

Silver architectural window film type external one-way mirror ORACAL Commercial S-EXTERIOR 20%, for use on external building windows, multi-layer, metallised, medium brightness, transmits approx. 21.8% of visible light. For external use. Available in widths. 152 cm, glossy surface.

Technical data

• Visible light transmission - 21.8%
• Visible light reflection - 52.3%
• Solar energy transmission - 17.2%
• Solar energy reflection - 55.9%
• Solar energy absorption - 26.9%
• IR reduction - 82%
• UV reduction - 99%
• TSER (Total Solar Energy Rejected) - 74.7%
• Glare reduction - 76%
• Thickness - 75 microns
• Durability - 3 years - in Central European climate conditions, when properly applied
• Material - Single-sided silicone-coated transparent polyester (silicone: 0.25 g/m²)
• Adhesive - Acrylic adhesive, repositionable, transparent.

Silver architectural window film type external one-way mirror ORACAL Commercial S-EXTERIOR 30%, for use on external building windows, multi-layer, metallised, light, transmits approx. 38% of visible light. For external use. Available in widths. 152 cm, glossy surface.

Technical data

• Visible light transmission - 38%
• Visible light reflection - 34.2%
• Solar energy transmission - 27.7%
• Solar energy reflection - 43.3%
• Solar energy absorption - 29%
• IR reduction - 71%
• UV reduction - 99%
• TSER (Total Solar Energy Rejected) - 61.2%
• Glare reduction - 58%
• Thickness - 75 microns
• Durability - 3 years - in Central European climate conditions, when properly applied
• Material - Single-sided silicone-coated transparent polyester (silicone: 0.25 g/m²)
• Adhesive - Acrylic adhesive, repositionable, transparent.

Silver architectural window film type external one-way mirror ORACAL Commercial S-EXTERIOR 50%, for use on external building windows, multi-layer, metallised, very bright, transmits approx. 52.8% of visible light. For external use. Available in widths. 152 cm, glossy surface.

Technical data

• Visible light transmission - 52.8%
• Visible light reflection - 16.8%
• Solar energy transmission - 45.2%
• Solar energy reflection - 23.5%
• Solar energy absorption - 31.3%
• IR reduction - 48%
• UV reduction - 99%
• TSER (Total Solar Energy Rejected) - 39.9%
• Glare reduction - 29%
• Thickness - 75 microns
• Durability - 3 years - in Central European climate conditions, when properly applied
• Material - Single-sided silicone-coated transparent polyester (silicone: 0.25 g/m²)
• Adhesive - Acrylic adhesive, repositionable, transparent.

Installation recommendations: vertical installation on standard glass surfaces
For use on low-e insulated glass and triple-glazed windows.

When using ORACAL Commercial S-EXTERIOR WINDOW FILMS, It is extremely important to prepare the windows properly. The most effective way to clean windows is to use a window cleaning solution (water and window cleaner, etc.) and a rubber squeegee, which will remove all dirt thoroughly. Clean the windows at least twice and DO NOT use acid-based chemical solutions to prevent damage to the film. Remember to clean the window seals as well. Even the smallest residues on the windows will prevent the adhesive from bonding completely with the glass and cause bubbles and unevenness on the film.

Note:

The information contained in this technical data sheet is based on our knowledge and experience and can only be used as a source of information, not as a legal guarantee of the specific characteristics of Orafol films, i.e. specific quality, properties or durability.
You can contact ORAFOL Turkey for assistance with the application, removal, maintenance and use of ORAFOL films. Failure to follow the manufacturer's instructions may result in a reduction in the product's durability. ORAFOL does not give any guarantee and is not liable for applications that do not comply with the instructions for use and maintenance. Please contact ORAFOL Turkey for professional assistance.
Due to the wide variety of applications for ORACAL products and the continuous development and renewal of application techniques, the purchaser must thoroughly test the suitability and performance of the product for its intended use. The purchaser assumes the risk associated with its use. All specifications are subject to change without notice.

Product card – Venetian mirror film – COMMERCIAL – EXTERIOR
