Description
Oracal Commercial S-Series window films are double-layer silver/metallised architectural window films of appropriate thickness and various shades. ORACAL COMMERCIAL S are window films manufactured using advanced technology. They reflect sunlight, thereby reducing the amount of solar energy penetrating the interior of the building. Not suitable for use on vehicles, due to the mirror effect. The films are easy to apply using the appropriate tools and methods. Designed for wet application.
-
Description and properties of film with 2% light transmission
ORACAL Commercial S-Series 00% silver architectural window film, for use on building windows, multi-layered, metallised, dark, virtually blocking all light transmission and providing a two-way "mirror effect" , transmits approx. 2% of visible light. For indoor use. Available in widths. 152 cm, glossy surface.
Technical data
- Visible light transmission - 2.3%
- Visible light reflection - 87.7%
- Solar energy transmission - 0.4%
- Solar energy reflection - 85%
- Solar energy absorption - 14.6%
- IR reduction - 99.4%
- UV reduction - 99%
- TSER (Total Solar Energy Rejected) - 93.6%
- Glare reduction - 100%
- Thickness - 50 microns
- Durability - 7 years - in Central European climate conditions, with proper application
- Backing material - Single-sided silicone-coated transparent polyester (silicone: 0.25 g/m²)
- Adhesive - Acrylic adhesive, repositionable, transparent.
-
Description and properties of film with 5% light transmission
ORACAL Commercial S-Series 05% silver architectural window film, for use on building windows, multi-layer, metallised, medium dark, transmits approx. 5% of visible light. For indoor use. Available in widths. 152 cm, glossy surface.
Technical data
- Visible light transmission - 5.8%
- Visible light reflection - 77.7%
- Solar energy transmission - 4.8%
- Solar energy reflection - 65.3%
- Solar energy absorption - 29.9%
- IR reduction - 94%
- UV reduction - 99%
- TSER (Total Solar Energy Rejected) - 88.5%
- Glare reduction - 94%
- Thickness - 50 microns
- Durability - 7 years - in Central European climate conditions, with proper application
- Backing material - Single-sided silicone-coated transparent polyester (silicone: 0.25 g/m²)
- Adhesive - Acrylic adhesive, repositionable, transparent.
-
Description and properties of film with 21.8% light transmission
ORACAL Commercial S-Series 20% silver architectural window film, for use on windows in buildings, multi-layer, metallised, light-coloured, transmits approx. 21.8% of visible light. For indoor use. Available in widths. 152 cm, glossy surface.
Technical data
- Visible light transmission - 21.8%
- Visible light reflection - 56.7%.
- Solar energy transmission - 17.2%
- Solar energy reflection - 55.9%
- Solar energy absorption - 26.9%
- IR reduction - 82%
- UV reduction - 99%
- TSER (Total Solar Energy Rejected) - 74.7%
- Glare reduction - 76%
- Thickness - 50 microns
- Durability - 7 years - in Central European climate conditions, with proper application
- Material - Single-sided silicone-coated transparent polyester (silicone: 0.25 g/m²)
- Adhesive - Acrylic adhesive, repositionable, transparent.
-
Description and properties of film with 64.2% light transmission
ORACAL Commercial S-Series 60% silver architectural window film, for use on building windows, multi-layer, metallised, very bright, transmits approx. 64.2% of visible light. For indoor use. Available in widths. 152 cm, glossy surface.
Technical data
- Visible light transmission - 64.2%
- Visible light reflection - 14.9%
- Solar energy transmission - 5.5%
- Solar energy reflection - 15.8%
- Solar energy absorption - 29.7%
- IR reduction - 39%
- UV reduction - 99%
- TSER (Total Solar Energy Rejected) - 33.5%
- Glare reduction - 25%
- Thickness - 50 microns
- Durability - 7 years - in Central European climate conditions, with proper application
- Material - Single-sided silicone-coated transparent polyester (silicone: 0.25 g/m²)
- Adhesive - Acrylic adhesive, repositionable, transparent.
-
Recommendations for use and installation
Installation recommendations: Vertical installation on standard glass surfaces.
For use on single-pane and older-style double-pane glazing (non-low-e double-pane glazing).
When using ORACAL Commercial S-Series WINDOW FILMS It is extremely important to prepare the windows properly. The most effective way to clean windows is to use a window cleaning solution (water and window cleaner, etc.) and a rubber squeegee, which will remove all dirt thoroughly. Clean the windows at least twice and DO NOT use acid-based chemical solutions to prevent damage to the film. Remember to clean the window seals as well. Even the smallest residues on the windows will prevent the adhesive from bonding completely with the glass and cause bubbles and unevenness on the film.
- Product data sheet available for download
